สถานที่กำเนิด: | มณฑลซานตงจีน |
---|---|
ชื่อแบรนด์: | SH |
ได้รับการรับรอง: | ISO9001,CE |
หมายเลขรุ่น: | SHJM350, SHJM650, SHJM800 |
จำนวนสั่งซื้อขั้นต่ำ: | 1 ชุด |
ราคา: | US $7,500-13,950 / Set |
รายละเอียดการบรรจุ: | การบรรจุโครงเหล็กหรือการบรรจุภาชนะ |
เวลาการส่งมอบ: | ภายใน 15 วัน |
เงื่อนไขการชำระเงิน: | T/T, Western Union |
สามารถในการผลิต: | 1,000 ชุด / ปี |
ชื่อ: | เลื่อยวงเดือนที่มีความแม่นยำ | เงื่อนไข: | ใหม่ |
---|---|---|---|
การทำงาน: | การหั่นหั่นไม้/บอร์ด | พลังงานมอเตอร์หลัก: | 15กิโลวัตต์, 18.5กิโลวัตต์, 22กิโลวัตต์, 30กิโลวัตต์ |
มอเตอร์ให้อาหาร: | 1.5kW | เส้นผ่านศูนย์กลางล้อเลื่อย: | 700 มม. |
ขนาดความกว้างของเครื่องเจาะ: | 1,000 มม. | สูงสุด ความสูงของการประมวลผล: | 110 มม. |
ความเร็วในการให้อาหาร: | อินเวอร์เตอร์ ปรับความเร็วได้ | การรับประกัน:: | 1 ปี |
บริการหลังการขาย: | การสนับสนุนออนไลน์ การสนับสนุนด้านเทคนิควิดีโอ การว่าจ้างและการฝึกอบรม | ||
เน้น: | horizontal band saw machine,wood cutting band resaw,industrial horizontal band saw |
Beyond basic cutting, a precision resaw is an investment in productivity. Its core benefit lies in transforming challenging tasks—like salvaging expensive slabs or producing delicate veneers—into streamlined, repeatable processes. This is the definitive solution for professionals who require dependable performance day in and day out.
High-Output Efficiency with Power Feeding
Benefit: Dramatically increase production rates and achieve a perfect surface finish by automating the feed process. A power feeder provides a consistent, steady feed rate, which is crucial for both operator safety and optimal precision resawing.
Features Behind the Benefit: Driven by a high-torque motor and often paired with a carbide-tipped blade, the saw maintains consistent speed and power through the thickest materials.
Maximize Material Value and Versatility
Benefit: Recover the highest possible value from expensive lumber by efficiently resawing slabs and cants into thinner, usable boards. The wide resaw capacity opens up opportunities for diverse projects.
Typical Applications: Ideal for producing lumber, custom veneers, wood siding, and salvaging valuable material from live-edge slabs.
Model | SHJM-400 | SHJM-650 | SHJM-800 | SHJM-1000 |
Saw wheel diameter | 600MM | 700MM | 700MM | 700MM |
Max. processing width | 400MM | 650MM | 800MM | 1000MM |
Max. processing height | 110MM | 110MM | 110MM | 110MM |
Sawn min.thickness | 2MM | 2MM | 2MM | 2MM |
Feeding speed | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min |
Main motor power | 15KW | 18.5KW | 22KW | 30KW |
Feeding motor power | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
Sawn sizes setting | CNC digital | CNC digital | CNC digital | CNC digital |
Machine weight | 1850kgs | 2550kgs | 2750kgs | 3150kgs |
Precision Slice Horizontal Band Sawmill
Horizontal Resaw Band Saw Mills | |||
Model | SH350 | SH650 | SH800 |
Saw Wheel Diameter | 710 mm | 710 mm | 710 mm |
Maximum Cutting Width | 350 mm | 650 mm | 800 mm |
Maximum working Wood Height | 200 mm | 220 mm | 220 mm |
Max Sawing Height
|
100 mm | 110 mm | 110 mm |
Min Sawing Thickness
|
2 mm | 2mm | 2mm |
Feeding speed | Variable Frequency Adjusted Speed | ||
Main Electric Motor Power | 15 KW | 18.5 KW | 18.5KW |
Up/down motor | 0.37kw | 0.37kw | 0.37kw |
Feeding motor | 1.1kw | 1.1kw | 1.5kw |
Machine Weight | 1000 KG | 1200 KG | 1400 KG |
We stand behind the durability of our precision resaw bandsaws. Each machine is backed by a comprehensive warranty and supported by a dedicated service team, ensuring you have the parts and expertise you need to keep your production running smoothly.
Ready to transform your woodworking productivity? Contact our experts today to discuss your specific needs and find the perfect precision resaw bandsaw for your shop.
